Sliding-Window Rate Limiting for FastAPI with Redis

What You'll Build

A reusable sliding-window rate limiter wired into FastAPI via Depends(), backed by a Redis sorted set and a single atomic Lua script — with stricter limits on auth routes to block credential-stuffing attempts.

Prerequisites

• Python 3.11+
• Docker (for Redis) or a running Redis 7 instance
• Familiarity with FastAPI Depends() and async/await
• A virtual environment activated

Why sliding window vs. fixed window? A fixed-window counter resets on a clock boundary, letting a burst of 2 × limit requests squeeze through the reset seam. A sliding window counts only requests within the last N seconds relative to now, eliminating that spike.

Step 1 — Start Redis

# docker-compose.yml
services:
  redis:
    image: redis:7-alpine
    ports:
      - "6379:6379"
    command: redis-server --save "" --appendonly no

docker compose up -d

--save "" and --appendonly no disable persistence — appropriate for an ephemeral rate-limit store.

Step 2 — Install Dependencies

python -m venv .venv && source .venv/bin/activate   # macOS/Linux
pip install "fastapi>=0.111.0" "uvicorn[standard]>=0.29.0" "redis>=5.0.0"

redis>=5.0.0 is required for the aclose() async teardown API.

Step 3 — Implement the Rate Limiter

Create limiter.py:

import hashlib
import time
import uuid

import redis.asyncio as aioredis
from fastapi import HTTPException, Request, status

# Atomic Lua script: prune stale entries, count, conditionally admit
_SCRIPT = """
local key    = KEYS[1]
local now    = tonumber(ARGV[1])
local win    = tonumber(ARGV[2])
local limit  = tonumber(ARGV[3])
local member = ARGV[4]
redis.call('ZREMRANGEBYSCORE', key, 0, now - win)
local count = redis.call('ZCARD', key)
if count < limit then
    redis.call('ZADD', key, now, member)
    redis.call('EXPIRE', key, win)
    return 1
end
redis.call('EXPIRE', key, win)
return 0
"""


def _identifier(request: Request) -> str:
    auth = request.headers.get("Authorization", "")
    if auth.startswith("Bearer "):
        # Hash the token — raw bearer values never reach Redis
        digest = hashlib.sha256(auth[7:].encode()).hexdigest()[:16]
        return f"token:{digest}"
    forwarded = request.headers.get("X-Forwarded-For", "")
    ip = (
        forwarded.split(",")[0].strip()
        if forwarded
        else (request.client.host if request.client else "unknown")
    )
    return f"ip:{ip}"


class RateLimiter:
    """Dependency-injectable sliding-window rate limiter."""

    def __init__(self, requests: int = 60, window: int = 60):
        self.requests = requests
        self.window = window  # seconds

    async def __call__(self, request: Request) -> None:
        r: aioredis.Redis = request.app.state.redis
        key = f"rl:{_identifier(request)}"
        now = int(time.time())
        member = str(uuid.uuid4())
        allowed = await r.eval(
            _SCRIPT, 1, key,
            str(now), str(self.window), str(self.requests), member,
        )
        if not allowed:
            raise HTTPException(
                status_code=status.HTTP_429_TOO_MANY_REQUESTS,
                detail="Rate limit exceeded.",
                headers={"Retry-After": str(self.window)},
            )

Key design decisions:

Step 4 — Wire It Into FastAPI

# main.py
from contextlib import asynccontextmanager

import redis.asyncio as aioredis
from fastapi import Depends, FastAPI

from limiter import RateLimiter


@asynccontextmanager
async def lifespan(app: FastAPI):
    app.state.redis = aioredis.from_url(
        "redis://localhost:6379", decode_responses=False
    )
    yield
    await app.state.redis.aclose()


app = FastAPI(lifespan=lifespan)

# Tighter limit on auth routes prevents credential-stuffing
auth_limiter = RateLimiter(requests=5,   window=60)
api_limiter  = RateLimiter(requests=100, window=60)


@app.post("/auth/login", dependencies=[Depends(auth_limiter)])
async def login():
    return {"status": "authenticated"}


@app.get("/api/data", dependencies=[Depends(api_limiter)])
async def get_data():
    return {"data": "some payload"}

The lifespan context manager creates a connection pool on startup and drains it on shutdown. Two separate RateLimiter instances let you tune each route class independently without sharing state.

Advertisement

Shadow GPS — know where it is, always Real-time GPS tracking for vehicles, gear and loved ones. No monthly contracts.

Verify It Works

uvicorn main:app --reload

Test the auth endpoint — the 6th and 7th requests should 429:

for i in $(seq 1 7); do
  curl -s -o /dev/null -w "%{http_code}\n" \
    -X POST http://localhost:8000/auth/login
done

Expected output:

200
200
200
200
200
429
429

Inspect the sorted set directly:

docker exec -it $(docker compose ps -q redis) \
  redis-cli ZRANGE "rl:ip:127.0.0.1" 0 -1 WITHSCORES

You should see up to 5 UUID members with Unix-timestamp scores.

Troubleshooting

AttributeError: 'NoneType' object has no attribute 'host'
request.client is None behind some reverse proxies. Add uvicorn's proxy-headers middleware — but only after locking down which upstream IPs you trust, otherwise clients can spoof X-Forwarded-For:

from uvicorn.middleware.proxy_headers import ProxyHeadersMiddleware
app.add_middleware(ProxyHeadersMiddleware, trusted_hosts=["10.0.0.1"])

redis.exceptions.ConnectionError: Error 111 connecting to localhost:6379
Redis isn't reachable. Confirm the container is running (docker compose ps) and port 6379 isn't already occupied by another process.

Rate limits reset unexpectedly under memory pressure
If Redis has a maxmemory-policy that evicts keys (e.g., allkeys-lru), rate-limit keys can disappear early. Use a dedicated Redis instance or set --maxmemory-policy noeviction for the rate-limit store.

All callers hit limits instantly
If request.client is None and X-Forwarded-For is absent, every request falls back to the identifier "ip:unknown" and shares one counter. Add proxy-headers middleware or verify your load balancer injects the real client IP.

Next Steps

• Add X-RateLimit-Remaining / X-RateLimit-Reset response headers by reading ZCARD after admission and returning them via a custom Response.
• Switch to evalsha — load the script once with SCRIPT LOAD and call it by SHA to avoid resending the Lua source on every request at high RPS.
• Authenticated per-user limits — after JWT validation, swap the identifier to the sub claim for per-account accounting instead of per-IP.
• Explore slowapi — a production-grade FastAPI rate-limiting library that packages these ideas with decorator syntax and pluggable key functions.
